RKC Temperature Controller REX-C100
₨ 2,100.0
Model no: REX-C100
Size: 48mm*48mm
Rated Voltage: 250V AC
Input: K-type
Temperature Range: 0-1300c
- Dimensions:about48mm48mm110mm(APP)
- Measuring accuracy: 0.5%FS
- Cold-end compensation tolerance: 2 Celsius (can be modified by software in 0~50 Celsius )
- Resolution: 14 bit
- Sampling cycle: 0.5 Sec
- Process value (PV), Setting value (SV)
- Output, alarm and self-tuning can be indicated by: LED
- PIN control (including ON/OFF, step-type PID and continuous PID)
- Self-tuning control
- Relay output: contact capacity 250V AC 3A (resistive load)
- Alarm function output: 2 way
- Contact capacity of output: 250V AC 3A (resistive load)
- Setting value (SV): identical to measuring range (PV)
- Proportional band (P): 0~full range (ON/OFF control when set to 0)
- Detective temperature range:0 to 400 Celsius
- Insulation resistance: >50M ohm(500V DC)
- Insulation resistance: 1500V AC/min
- Power Consumption: 10 VA
- Service environment: 0~50 Celsius ,
- environment with no corrosive gas 30~85% RH
| Weight | 0.5 kg |
|---|
