Product: limit switch
Type: wheel with lever arm
Degree of protection : IP67
Durability (mechanical) : 15,000,000 operations min.
Rated voltage: 600v
Rated frequency : 50/60 Hz
Insulation resistance : 100 MO min. (at 500 VDC)
Ambient operating temperature : -10 to +80C (with no icing)
Ambient operating humidity : 35% to 95% RH
- This is a power limit switch which features a compact design and a long mechanical life.
- They have easy wiring with full open terminals and dust, water, oil proof construction.
- A strong body with a combination of reinforced plastic and aluminium Die Casting components.
- It is operated by the motion of a machine part or presence of an object.
- The defining feature of it is that a relatively small movement at the actuator button produces a relatively large movement at the electrical contacts, which occurs at high speed (regardless of the speed of actuation).
- click the image for full view.
